IoT RF Lora Sx1278 Module

Name: IoT RF Lora Sx1278 Module
Brand: Cansec Wireless
Price: 3.55 USD

Brand Name : Cansec Wireless

Model Number : LR1278NA-G

Place of Origin : Beijing

MOQ : 1000

Price : USD 3.55$ per piece

Payment Terms : T/T

Supply Ability : 20000000 units per year

Delivery Time : 5-8 weeks

Packaging Details : Three layers of protection anti-static bag & moisture-proof & cardboard box ensure transportation safety

Chipset : Semtech SX1278

Application : IoT

Size : 16*17*3mm

Operating Temperature : -20 - 70℃

Operating Voltage : 2.7-3.6V

TX Power : 20dBm

RX Sensitivity : -139dBm

Sleep Current Consumption : 0.1μA

Contact Now

IoT RF Lora Sx1278 Module

Low Power Consumption Long Range RF Transceiver Module IoT Industrial Solution Cansec LR1278Na-G SX1278 LoRa Module

Parameter		Min	Typ	Max	Unit
Operating Voltage		2.7	-	3.6	V
Operating Temperature		-20	-	+70	℃
Current Consumption	Sleep Mode	-	0.1	-	uA
	Receive mode	-	11.7	-	mA
	Transmit Mode (RFOP =+20dBm, on PA_BOOST)	-	117	-	mA
TX Power (For Carrier)		-	18	20	dBm
RX Sensitivity (For Lora Modulation)		-	-	-139	dBm

Low Power Consumption Long Range RF Transceiver Module IoT Industrial Solution Cansec LR1278Na-G SX1278 LoRa Module

The LR1278NA-G module is designed based on SX1278. The SX1278 incorporates the LoRaTM spread spectrum modem which is capable of achieving significantly longer range than existing systems based on FSK or OOK modulation. LoRaTM also provides significant advances in selectivity and blocking performance, further improving communication reliability.

​

FAQ
Q1: Are you a factory or trade company?
A1: We are a professional factory with 25 years experience.

Q2: Can you accept OEM/ODM?
A2: Sure, we have rich OEM&ODM experience.

Q3: Do you have quality assurance?
A3; Each of our products has undergone quality testing and has two years of free after-sales service.
